Product DescriptionDS18B20 Instead of reading a voltage with an analog pin, we read a serial stream of bits from the sensor on one of our digital pins. One such sensor is the Dallas Semiconductor DS18B20. It uses what Dallas Semiconductor calls the OneWire protocol to communicate back and forth between the sensor and the tiny computer. It has three pins, one for power, one for ground, and one for the data link (it is this single data link line that gives the protocol its name).
DS18B20 is a commonly used digital temperature sensor, and its output is digital signal. It has the characteristics of small size, low hardware overhead, strong anti-interference ability and high precision.
Votesen VTS200 is a DS18B20 digital temperature sensor which composed of original DALLAS chip, stainless steel probe, cable and connector.
PRODUCT PARAMETER
| Digital Chip |
100% Original DALLAS |
| Power Supply |
3.0~5.5VDC |
| Temperature Range |
-55℃~+125℃ |
| Probe Dimension |
Diameter:¢6~¢9mm, length:10mm~1000mm |
| Cable Length |
0.5M, 1M, 2M etc. Customization available. |
| Accuracy |
-10~+85℃, the accuracy is ±0.5℃ |
| Resolution Ratio |
9~12 bit |
| Probe Material |
Stainless Steel, Customization available. |
| Cable Material |
PVC,Silicone,PTFEetc,Customization available. |
| Connector |
MOLEX,JST,DuPont,CJT,Utype etc.Customization available. |
| Connection Mode |
Black: GND, Yellow: DATA, Red: VDD+ |
PRODUCT FEATURE
1. Digital Signal Output
One Wire interface requires only one port pin for communication. Requires no external components.
2. High Accuracy
Operating temperature range: -55°C to +125°C (-67F to +257F), ±0.5°C accuracy from -10°C to +85°C.
3. Data Line Power Supply
Can be powered from data line. Power supply range is 3.0V to 5.5V.
4. Fast Response
Thermometer resolution is programmable from 9 to 12 bits.
5.Various Probe Design
Probe dimension :6*30mm or customized
HOW TO ORDER?
Send us the below details and we will be able to assist you based on your requirements.
1. Operation Temperature range
2. Application
3. Probe Dimension
4. Types of Probe
5. Cable Length
5. Cable Connector
6. Any other specific request
APPLICATION
Water Temperature Monitoring, HVAC, Medical Instrument, GPS Oil Tank Temperature Monitoring etc.
PRODUCT FAQ
Q: Where physically on the device does the temperature measurement take place?
A: The DS18B20 does not sense temperature directly through the package. For all package types, the DS18B20 senses temperature primarily through the GND pin. Ensuring a good thermal connection between the GND pin of the device and the heat source you wish to measure will provide the best results.
Q: Is there a way to extend the temperature range of the DS18B20?
A: No, there is not a way to increase the range it reads. The DS18B20 reads with an accuracy of ±0.5°C from -10°C to +85°C and ±2°C accuracy from -55°C to +125°C.
Q: Will a conformal coating affect the thermal response of the DS18B20?
A: A thin conformal coating will not affect the thermal response of the device.
Q: Using OneWireViewer, can more than one DS18B20 be logged?
A: Yes, every DS18B20 will have a file where you can store the data. Data will be received from one DS18B20 at a time.
Q: Can you power the DS18B20 from a 3V battery?
A: The DS18B20 can be powered from any source. Since batteries will dip in voltage, a nominal 3V battery may not always supply the minimum 3.0V the DS18B20 requires. We suggest a step-up voltage regulator is used to ensure the device is supplied within its rated voltage range of 3.0V to 5.5V.
Precision 9–12 Bit Digital ReadingsThe VOTESEN 6×50 mm Stainless Steel DS18B20 delivers high-resolution digital temperature data, selectable between 9- and 12-bit modes for adaptable applications. As a reliable DS18B20 Digital Temperature Sensor, it provides consistent readings crucial for process control, HVAC systems, and instrumentation. With factory calibration and digital output, this stainless steel temperature sensor ensures both accuracy and traceability across industrial environments.
Robust Stainless Steel ConstructionEncased in corrosion-resistant 316 stainless steel, this Stainless Steel Temperature Sensorwithstands harsh conditions like moisture, chemicals, and mechanical wear. Whether monitoring in factories, food processing, or outdoor setups, its durable probe resists environmental stress, ensuring long-term stability and minimal maintenance.
Low Power and Fast Thermal ResponseEngineered with efficiency in mind, the digital probe operates with minimal power consumption, making it suitable for battery-powered systems and remote deployment. The responsive stainless steel sheath enables rapid thermal exchange, delivering near-instantaneous readings. This makes VOTESEN’s DS18B20 probe ideal for real-time alerts and control systems in temperature-sensitive processes.
Versatile Integration with Digital InterfaceFeaturing the standard 1-Wire DS18B20 interface, this Digital Temperature Sensor Probeintegrates seamlessly with ds18b20-compatible controllers, PLCs, and data loggers. Multi-drop capability allows multiple sensors on one bus, reducing wiring complexity. The plug-and-play design simplifies installation and scale‑up in industrial automation projects.
- High Accuracy: Offers ±0.5 °C precision at 12-bit resolution. VOTESEN’s DS18B20 Digital Temperature Sensor ensures reliable data for critical control applications.
- Durable Build: 316 stainless steel housing resists corrosion and physical stress, qualifying it as a versatile Stainless Steel Temperature Sensor for harsh environments.
- Selectable Resolution: Switch between 9–12 bit resolution to adjust between speed and precision. Ideal for applications requiring fast cycles or detailed temperature measurement.
- Energy Efficient & Fast Response: Minimal power draw combined with rapid thermal sensing ensures efficient operation and prompt feedback in dynamic systems.
- Easy 1‑Wire Integration: DS18B20 digital interface supports multiple sensors on one line. Simplifies installation and expands scalability in automated setups.
